● Freq. range: 0.01-18GHz
● High Isolation, Low VSWR
● Stable for military environment
● Customization is available
| Part # | No. of Ways | RF Low (GHz) | RF High (GHz) | Insertion Loss (dB) Max. | VSWR (:1) Max. | Isolation (dB) Min. | RF Power (dBm) Max. | Amplitude Unbalance (dB) Max. | Phase Unbalance (deg) Max. | Connector |
|---|---|---|---|---|---|---|---|---|---|---|
| HPD-2-10M1G-A | 2 | 0.01 | 1 | 0.3 | 1.3 | 25 | 60 | 0.3 | 4 | N-Female |
| HPD-2-500M2G-A | 2 | 0.5 | 2 | 0.3 | 1.2 | 25 | 57 | 0.3 | 4 | SMA-Female |
| HPD-2-2G4G-A | 2 | 2 | 4 | 0.5 | 1.5 | 25 | 57 | 0.5 | 5 | SMA-Female |
| HPD-2-4G6G-A | 2 | 4 | 6 | 0.6 | 1.5 | 20 | 57 | 0.5 | 5 | SMA-Female |
| HPD-2-8G12G-A | 2 | 8 | 12 | 0.6 | 1.5 | 18 | 53 | 0.8 | 10 | SMA-Female |
| HPD-2-6G18G-A | 2 | 6 | 18 | 1 | 1.5 | 18 | 50 | 0.8 | 10 | SMA-Female |
