● Insertion Loss ≤ 1.0dB
● Hangtod sa 15W
● Lapad sa temperatura nga sakop: -55℃ hangtod +85℃
● Compact nga gidak-on
● Ma-customize nga mga konfigurasyon
| Part # | Cut off Freq. GHz | Pass Band Freq. GHz | Insertion Loss | VSWR (dB Typ.) | Stop Band Attenuation (Typ.) | Gahum | Mga konektor | Gidak-on((LxWxH))mm |
|---|---|---|---|---|---|---|---|---|
| HSF-3314-A | 1.0 | 1.0～10 | ≤1.0 | ≤1.5:1 | ≥50@DC～0.78 | 15 | SMA-Female | 61x23x10 |
| HSF-3315-A | 1.25 | 1.25～12 | ≤1.0 | ≤1.5:1 | ≥50@DC～0.98 | 15 | SMA-Female | 52x20.5x10 |
| HSF-3316-A | 1.5 | 1.5～14 | ≤1.0 | ≤1.5:1 | ≥50@DC～1.17 | 15 | SMA-Female | 46x20x10 |
| HSF-3317-A | 1.75 | 1.75～17 | ≤1.0 | ≤1.5:1 | ≥50@DC～1.38 | 15 | SMA-Female | 40x18x10 |
| HSF-3318-A | 2.0 | 2.0～19 | ≤1.0 | ≤1.5:1 | ≥50@DC～1.58 | 15 | SMA-Female | 37x18x10 |
| HSF-3319-A | 2.25 | 2.25～19 | ≤1.0 | ≤1.5:1 | ≥50@DC～1.77 | 15 | SMA-Female | 35x17.5x10 |
| HSF-3320-A | 2.5 | 2.5～20 | ≤1.0 | ≤1.5:1 | ≥50@DC～1.98 | 15 | SMA-Female | 35x17x10 |
| HSF-3321-A | 2.75 | 2.75～21 | ≤1.0 | ≤1.5:1 | ≥50@DC～2.2 | 15 | SMA-Female | 33x17x10 |
| HSF-3322-A | 3.0 | 3.0～21 | ≤1.0 | ≤1.5:1 | ≥50@DC～2.36 | 15 | SMA-Female | 31x16.5x10 |
| HSF-3323-A | 3.25 | 3.25～22 | ≤1.0 | ≤1.5:1 | ≥50@DC～2.57 | 15 | SMA-Female | 30x16.5x10 |
| HSF-3324-A | 3.5 | 3.5～23 | ≤1.0 | ≤1.5:1 | ≥50@DC～2.77 | 15 | SMA-Female | 28x16x10 |
| HSF-3325-A | 3.75 | 3.75～23 | ≤1.0 | ≤1.5:1 | ≥50@DC～3.03 | 15 | SMA-Female | 26x16x10 |
| HSF-3326-A | 4.0 | 4.0～23 | ≤1.0 | ≤1.5:1 | ≥50@DC～3.2 | 15 | SMA-Female | 25x16x10 |
| HSF-3327-A | 4.25 | 4.25～23 | ≤1.0 | ≤1.5:1 | ≥50@DC～3.4 | 15 | SMA-Female | 24x16x10 |
| HSF-3328-A | 4.5 | 4.5～23.5 | ≤1.0 | ≤1.5:1 | ≥50@DC～3.55 | 15 | SMA-Female | 24x16x10 |
| HSF-3329-A | 5.0 | 5.0～24 | ≤1.0 | ≤1.5:1 | ≥50@DC～4.0 | 15 | SMA-Female | 23x16x10 |
| HSF-3330-A | 5.5 | 5.5～24.5 | ≤1.0 | ≤1.5:1 | ≥50@DC～4.5 | 15 | SMA-Female | 22x16x10 |
| HSF-3331-A | 6.0 | 6.0～24.5 | ≤1.0 | ≤1.5:1 | ≥50@DC～4.9 | 15 | SMA-Female | 22x16x10 |
| HSF-3332-A | 6.5 | 6.5～25 | ≤1.0 | ≤1.5:1 | ≥50@DC～5.4 | 15 | SMA-Female | 21x15x10 |
| HSF-3333-A | 7.0 | 7.0～26 | ≤1.0 | ≤1.5:1 | ≥50@DC～5.85 | 15 | SMA-Female | 20x15x10 |
| HSF-2832-A | 7.5 | 7.5～27 | ≤1.0 | ≤1.5:1 | ≥50@DC～6.25 | 15 | SMA-Female | 20x15x10 |
| HSF-3334-A | 8.0 | 8.0～28 | ≤1.0 | ≤1.5:1 | ≥50@DC～6.65 | 15 | SMA-Female | 19x15x10 |
| HSF-3335-A | 8.5 | 8.5～28 | ≤1.0 | ≤1.5:1 | ≥50@DC～7.1 | 15 | SMA-Female | 19x15x10 |
| HSF-3011-A | 9.0 | 9.0～28 | ≤1.0 | ≤1.5:1 | ≥50@DC～7.45 | 15 | SMA-Female | 19x15x10 |
| HSF-3336-A | 9.5 | 9.5～28 | ≤1.0 | ≤1.5:1 | ≥50@DC～7.93 | 15 | SMA-Female | 19x15x10 |
| HSF-3337-A | 10 | 10～28 | ≤1.0 | ≤1.5:1 | ≥50@DC～8.25 | 15 | SMA-Female | 19x15x10 |
| HSF-3338-A | 10.5 | 10.5～28 | ≤1.0 | ≤1.6:1 | ≥50@DC～8.5 | 15 | SMA-Female | 15x12.7x10 |
| HSF-3338-A | 10.5 | 10.5～40 | ≤1.0 | ≤1.8:1 | ≥50@DC～8.5 | 15 | 2.92mm-Pinay | 15x12.7x10 |
| HSF-3339-A | 11 | 11～28 | ≤1.0 | ≤1.6:1 | ≥50@DC～9.0 | 15 | SMA-Female | 15x12.7x10 |
| HSF-3339-A | 11 | 11～40 | ≤1.0 | ≤1.8:1 | ≥50@DC～9.0 | 15 | 2.92mm-Pinay | 15x12.7x10 |
| HSF-3340-A | 11.5 | 11.5～28 | ≤1.0 | ≤1.6:1 | ≥50@DC～9.3 | 15 | SMA-Female | 15x12.7x10 |
| HSF-3340-A | 11.5 | 11.5～40 | ≤1.0 | ≤1.8:1 | ≥50@DC～9.3 | 15 | 2.92mm-Pinay | 15x12.7x10 |
| HSF-3341-A | 12 | 12～28 | ≤1.0 | ≤1.6:1 | ≥50@DC～9.6 | 15 | SMA-Female | 15x12.7x10 |
| HSF-3341-A | 12 | 12～40 | ≤1.0 | ≤1.8:1 | ≥50@DC～9.6 | 15 | 2.92mm-Pinay | 15x12.7x10 |
| HSF-3141-A | 18 | 18～40 | ≤1.0 | ≤1.8:1 | ≥50@DC～15 | 15 | 2.92mm-Pinay | 12.7x12.7x10 |
| HSF-3141-A | 18 | 18～28 | ≤1.0 | ≤1.8:1 | ≥50@DC～15 | 15 | SMA-Female | 12.7x12.7x10 |
| Part # | Cut off Freq. GHz | Pass Band Freq. GHz | Insertion Loss | VSWR (dB Typ.) | Stop Band Attenuation (Typ.) | Gahum | Mga konektor | Gidak-on((LxWxH))mm |
|---|---|---|---|---|---|---|---|---|
| HSF-3282-A | 1.0 | 1.0～6.0 | ≤1.0 | ≤1.6:1 | ≥60@DC～0.86 | 15 | SMA-Female | 102x39x10 |
| HSF-1790-A | 1.25 | 1.25～7.0 | ≤1.0 | ≤1.5:1 | ≥60@DC～1.04 | 15 | SMA-Female | 86x36x10 |
| HSF-3283-A | 1.5 | 1.5～8.0 | ≤1.0 | ≤1.5:1 | ≥60@DC～1.28 | 15 | SMA-Female | 76x34x10 |
| HSF-3284-A | 1.75 | 1.75～10 | ≤1.0 | ≤1.5:1 | ≥60@DC～1.47 | 15 | SMA-Female | 68x30x10 |
| HSF-3285-A | 2.0 | 2.0～13 | ≤1.0 | ≤1.5:1 | ≥60@DC～1.7 | 15 | SMA-Female | 56x36x10 |
| HSF-3286-A | 2.25 | 2.25～14 | ≤1.0 | ≤1.5:1 | ≥60@DC～1.93 | 15 | SMA-Female | 52x32x10 |
| HSF-3287-A | 2.5 | 2.5～15 | ≤1.0 | ≤1.5:1 | ≥60@DC～2.15 | 15 | SMA-Female | 49x32x10 |
| HSF-3288-A | 2.75 | 2.75～16 | ≤1.0 | ≤1.5:1 | ≥60@DC～2.36 | 15 | SMA-Female | 45x30x10 |
| HSF-2833-A | 3.0 | 3.0～18 | ≤1.0 | ≤1.5:1 | ≥60@DC～2.6 | 15 | SMA-Female | 44x29x10 |
| HSF-3289-A | 3.25 | 3.25～18 | ≤1.0 | ≤1.5:1 | ≥60@DC～2.83 | 15 | SMA-Female | 42x28x10 |
| HSF-1935-A | 3.5 | 3.5～19 | ≤1.0 | ≤1.5:1 | ≥60@DC～3.08 | 15 | SMA-Female | 41x29x10 |
| HSF-3290-A | 3.75 | 3.75～19 | ≤1.0 | ≤1.5:1 | ≥60@DC～3.3 | 15 | SMA-Female | 39x28x10 |
| HSF-2638-A | 4.0 | 4.0～20 | ≤1.0 | ≤1.5:1 | ≥60@DC～3.55 | 15 | SMA-Female | 39x28x10 |
| HSF-3291-A | 4.25 | 4.25～20 | ≤1.0 | ≤1.5:1 | ≥60@DC～3.78 | 15 | SMA-Female | 36x25x10 |
| HSF-3292-A | 4.5 | 4.5～21 | ≤1.0 | ≤1.5:1 | ≥60@DC～3.98 | 15 | SMA-Female | 36x25x10 |
| HSF-3293-A | 5.0 | 5.0～22 | ≤1.0 | ≤1.5:1 | ≥60@DC～4.48 | 15 | SMA-Female | 35x25x10 |
| HSF-3294-A | 5.5 | 5.5～23 | ≤1.0 | ≤1.5:1 | ≥60@DC～4.95 | 15 | SMA-Female | 33x24x10 |
| HSF-3295-A | 6.0 | 6.0～24 | ≤1.0 | ≤1.5:1 | ≥60@DC～5.4 | 15 | SMA-Female | 32x23x10 |
| HSF-3296-A | 6.5 | 6.5～24 | ≤1.0 | ≤1.5:1 | ≥60@DC～5.83 | 15 | SMA-Female | 31x21x10 |
| HSF-3297-A | 7.0 | 7.0～24 | ≤1.0 | ≤1.5:1 | ≥60@DC～6.3 | 15 | SMA-Female | 30x21x10 |
| HSF-3298-A | 7.5 | 7.5～24.5 | ≤1.0 | ≤1.5:1 | ≥60@DC～6.77 | 15 | SMA-Female | 30x21x10 |
| HSF-1944-A | 8.0 | 8.0～25 | ≤1.0 | ≤1.5:1 | ≥60@DC～7.25 | 15 | SMA-Female | 29x21x10 |
| HSF-3299-A | 8.5 | 8.5～25 | ≤1.0 | ≤1.5:1 | ≥60@DC～7.68 | 15 | SMA-Female | 28x20x10 |
| HSF-3300-A | 9.0 | 9.0～23 | ≤1.0 | ≤1.5:1 | ≥60@DC～8.22 | 15 | SMA-Female | 29x23x10 |
| HSF-3301-A | 9.5 | 9.5～23.5 | ≤1.0 | ≤1.5:1 | ≥60@DC～8.7 | 15 | SMA-Female | 29x22x10 |
| HSF-3302-A | 10 | 10～24 | ≤1.0 | ≤1.5:1 | ≥60@DC～9.17 | 15 | SMA-Female | 28x22x10 |
| HSF-3303-A | 10.5 | 10.5～24 | ≤1.0 | ≤1.6:1 | ≥60@DC～9.58 | 15 | SMA-Female | 27x22x10 |
| HSF-3304-A | 11 | 11～24 | ≤1.0 | ≤1.6:1 | ≥60@DC～10.07 | 15 | SMA-Female | 27x21x10 |
| HSF-3305-A | 11.5 | 11.5～24 | ≤1.0 | ≤1.6:1 | ≥60@DC～10.55 | 15 | SMA-Female | 27x21x10 |
| HSF-3306-A | 12 | 12～24.5 | ≤1.0 | ≤1.6:1 | ≥60@DC～11 | 15 | SMA-Female | 27x20x10 |
| HSF-3307-A | 12.5 | 12.5～24.5 | ≤1.0 | ≤1.6:1 | ≥60@DC～11.4 | 15 | SMA-Female | 27x20x10 |
| HSF-3308-A | 13 | 13～24.5 | ≤1.0 | ≤1.6:1 | ≥60@DC～11.95 | 15 | SMA-Female | 26x20x10 |
| HSF-3309-A | 13.5 | 13.5～24.5 | ≤1.0 | ≤1.6:1 | ≥60@DC～12.4 | 15 | SMA-Female | 26x20x10 |
| HSF-3310-A | 14 | 14～25 | ≤1.0 | ≤1.6:1 | ≥60@DC～12.82 | 15 | SMA-Female | 25x19x10 |
| HSF-3311-A | 14.5 | 14.5～25 | ≤1.0 | ≤1.6:1 | ≥60@DC～13.3 | 15 | SMA-Female | 25x19x10 |
| HSF-3312-A | 15 | 15～25 | ≤1.0 | ≤1.6:1 | ≥60@DC～13.7 | 15 | SMA-Female | 24x19x10 |
| HSF-3313-A | 18 | 18～46 | ≤1.0 | ≤1.7:1 | ≥60@DC～16.2 | 15 | 2.92mm-Pinay | 18x16x10 |
| Part # | Cut off Freq. GHz | Pass Band Freq. GHz | Insertion Loss | VSWR (dB Typ.) | Stop Band Attenuation (Typ.) | Gahum | Mga konektor | Gidak-on((LxWxH))mm |
|---|---|---|---|---|---|---|---|---|
| LSF-3250-A | 1.0 | DC～1.0 | ≤1.0 | ≤1.3:1 | ≥70@1.3～4.2 | 15 | SMA-Female | 82x27x10 |
| LSF-1931-A | 1.25 | DC～1.25 | ≤1.0 | ≤1.3:1 | ≥60@1.52～4.7 | 15 | SMA-Female | 66x27x10 |
| LSF-3251-A | 1.5 | DC～1.5 | ≤1.0 | ≤1.3:1 | ≥60@1.8～5.3 | 15 | SMA-Female | 69x26x10 |
| LSF-2041-A | 1.75 | DC～1.75 | ≤1.0 | ≤1.3:1 | ≥60@2.1～5.8 | 15 | SMA-Female | 64x24x10 |
| LSF-3252-A | 2.0 | DC～2.0 | ≤1.0 | ≤1.3:1 | ≥60@2.38～7.0 | 15 | SMA-Female | 61x24x10 |
| LSF-1932-A | 2.25 | DC～2.25 | ≤1.0 | ≤1.3:1 | ≥60@2.65～7.4 | 15 | SMA-Female | 55x24x10 |
| LSF-3253-A | 2.5 | DC～2.5 | ≤1.0 | ≤1.3:1 | ≥60@2.95～7.7 | 15 | SMA-Female | 53x23x10 |
| LSF-3254-A | 2.75 | DC～2.75 | ≤1.0 | ≤1.3:1 | ≥60@3.17～8.5 | 15 | SMA-Female | 51x23x10 |
| LSF-3255-A | 3.0 | DC～3.0 | ≤1.0 | ≤1.3:1 | ≥60@3.52～10 | 15 | SMA-Female | 44x24x10 |
| LSF-3256-A | 3.25 | DC～3.25 | ≤1.0 | ≤1.3:1 | ≥60@3.74～10.5 | 15 | SMA-Female | 42x24x10 |
| LSF-3257-A | 3.5 | DC～3.5 | ≤1.0 | ≤1.3:1 | ≥60@4.05～11.5 | 15 | SMA-Female | 38x24x10 |
| LSF-3258-A | 3.75 | DC～3.75 | ≤1.0 | ≤1.3:1 | ≥60@4.25～11.8 | 15 | SMA-Female | 38x24x10 |
| LSF-1933-A | 4.0 | DC～4.0 | ≤1.0 | ≤1.3:1 | ≥60@4.5～12.3 | 15 | SMA-Female | 35x23x10 |
| LSF-3259-A | 4.25 | DC～4.25 | ≤1.0 | ≤1.3:1 | ≥60@4.77～12.8 | 15 | SMA-Female | 35x23x10 |
| LSF-3260-A | 4.5 | DC～4.5 | ≤1.0 | ≤1.3:1 | ≥60@5.1～13.7 | 15 | SMA-Female | 34x23x10 |
| LSF-3261-A | 5.0 | DC～5.0 | ≤1.0 | ≤1.3:1 | ≥60@5.58～15 | 15 | SMA-Female | 31x22x10 |
| LSF-3262-A | 5.5 | DC～5.5 | ≤1.0 | ≤1.3:1 | ≥60@6.07～15.1 | 15 | SMA-Female | 30x22x10 |
| LSF-2042-A | 6.0 | DC～6.0 | ≤1.0 | ≤1.3:1 | ≥60@6.7～15.5 | 15 | SMA-Female | 29x22x10 |
| LSF-2043-A | 6.5 | DC～6.5 | ≤1.0 | ≤1.3:1 | ≥60@7.27～15.3 | 15 | SMA-Female | 31x23x10 |
| LSF-1934-A | 7.0 | DC～7.0 | ≤1.0 | ≤1.3:1 | ≥50@7.77～15.5 | 15 | SMA-Female | 31x23x10 |
| LSF-3263-A | 7.5 | DC～7.5 | ≤1.0 | ≤1.4:1 | ≥50@8.3～15.8 | 15 | SMA-Female | 30x22x10 |
| LSF-3264-A | 8.0 | DC～8.0 | ≤1.0 | ≤1.4:1 | ≥50@8.8～16.2 | 15 | SMA-Female | 30x22x10 |
| LSF-3265-A | 8.5 | DC～8.5 | ≤1.0 | ≤1.4:1 | ≥50@9.3～17 | 15 | SMA-Female | 29x21x10 |
| LSF-3266-A | 9.0 | DC～9.0 | ≤1.0 | ≤1.4:1 | ≥50@9.8～17 | 15 | SMA-Female | 29x21x10 |
| LSF-3267-A | 9.5 | DC～9.5 | ≤1.0 | ≤1.4:1 | ≥50@10.3～18 | 15 | SMA-Female | 29x21x10 |
| LSF-3268-A | 10 | DC～10 | ≤1.0 | ≤1.4:1 | ≥50@10.9～18.5 | 15 | SMA-Female | 28x21x10 |
| LSF-3269-A | 10.5 | DC～10.5 | ≤1.0 | ≤1.4:1 | ≥50@11.65～18.5 | 15 | SMA-Female | 27x20x10 |
| LSF-3270-A | 11 | DC～11 | ≤1.0 | ≤1.5:1 | ≥50@12.1～19 | 15 | SMA-Female | 24x19x10 |
| LSF-3271-A | 11.5 | DC～11.5 | ≤1.0 | ≤1.5:1 | ≥50@12.6～20 | 15 | SMA-Female | 24x19x10 |
| LSF-3272-A | 12 | DC～12 | ≤1.0 | ≤1.5:1 | ≥50@13.1～20 | 15 | SMA-Female | 24x19x10 |
| LSF-3273-A | 12.5 | DC～12.5 | ≤1.0 | ≤1.5:1 | ≥50@13.7～20 | 15 | SMA-Female | 24x19x10 |
| LSF-3274-A | 13 | DC～13 | ≤1.0 | ≤1.5:1 | ≥50@14.1～21 | 15 | SMA-Female | 22x17.5x10 |
| LSF-3275-A | 13.5 | DC～13.5 | ≤1.0 | ≤1.5:1 | ≥50@14.7～21.3 | 15 | SMA-Female | 22x17.5x10 |
| LSF-3276-A | 14 | DC～14 | ≤1.0 | ≤1.5:1 | ≥50@15.2～21.7 | 15 | SMA-Female | 22x17.5x10 |
| LSF-3277-A | 14.5 | DC～14.5 | ≤1.0 | ≤1.5:1 | ≥50@15.7～22 | 15 | SMA-Female | 22x17.5x10 |
| LSF-2489-A | 15 | DC～15 | ≤1.0 | ≤1.5:1 | ≥50@16～22.3 | 15 | SMA-Female | 21x17x10 |
| LSF-2490-A | 15.5 | DC～15.5 | ≤1.0 | ≤1.5:1 | ≥50@16.5～22.5 | 15 | SMA-Female | 21x17x10 |
| LSF-2491-A | 16 | DC～16 | ≤1.0 | ≤1.5:1 | ≥50@17～22.8 | 15 | SMA-Female | 21x17x10 |
| LSF-2492-A | 16.5 | DC～16.5 | ≤1.0 | ≤1.5:1 | ≥50@17.5～23 | 15 | SMA-Female | 21x17x10 |
| LSF-3278-A | 17 | DC～17 | ≤1.0 | ≤1.6:1 | ≥50@18.1～24 | 15 | SMA-Female | 18x17x10 |
| LSF-3279-A | 17.5 | DC～17.5 | ≤1.0 | ≤1.6:1 | ≥50@18.6～25 | 15 | SMA-Female | 18x17x10 |
| LSF-3280-A | 18 | DC～18 | ≤1.0 | ≤1.6:1 | ≥50@19.1～26 | 15 | SMA-Female | 18x17x10 |
| LSF-3281-A | 18.5 | DC～18.5 | ≤1.0 | ≤1.6:1 | ≥50@19.6～26 | 15 | SMA-Female | 18x17x10 |
| LSF-2331-A | 19 | DC～19 | ≤1.0 | ≤1.6:1 | ≥50@20.1～26 | 15 | SMA-Female | 17x17x10 |
| LSF-2330-A | 20 | DC～20 | ≤1.0 | ≤1.6:1 | ≥50@21.2～27 | 15 | SMA-Female | 17x17x10 |
| LSF-2332-A | 21 | DC～21 | ≤1.0 | ≤1.6:1 | ≥50@22.2～27 | 15 | SMA-Female | 17x17x10 |
